Broadcast Level 4K HDMI to 12G-SDI video converter based on broadcast SDI signal design. The SDI input supports up to 12G SDI. The HDMI input supports up to 4K@60Hz, and is compatible with 1080P, 1080I, 720P, 576I and 480I resolutions.
The device uses pure hardware architecture with fast startup, low power consumption and no delay output. It can be widely used in professional broadcast television equipment, medical equipment, high-definition conference systems, high-definition teaching equipment, signal transmission, security monitoring and multimedia advertising applications. For signals that comply with the SMPTE standard, the device automatically detects the output and the input signal remains at one point without additional settings
Features
1. HDMI2.0 version input, compatible with lower
2. 12G-SDI output, Compatible with 6G-SDI, 3G-SDI, HD-SDI, SD-SDI
3. Max resolution up to 3840X2160@60Hz
4. Bandwidth range from 270Mb/s to11.88Gb/s
5. Automatically detect HDMI input signal version
6. Built-in SDI signal equalization, clock recovery
7. 5V-12V DC power supply
8. Support LED indicator status
Specifications
|
Mode |
HDMI2.0 to 12G-SDI |
|
Size |
Shell: 10.3x7.1cm PCB: 10x6.7cm |
|
Input |
HDMI2.0x1 |
|
HDMI Impedance |
100Ω |
|
Output |
SDIX1 |
|
SDI Impedance |
75Ω BNC |
|
SDI Format |
12G-SDI, 6G-SDI, 3G-SDI,HD-SDI,SD-SDI |
|
Resolution |
4K@50/59.94/60fps, 4K@23.98/24/25/29.97/30fps 1080P@50/59.94/60fps, 1080P@23.98/24/25/29.97/30fps 1080I@50/59.94/60fps, 720P@50/59.94/60fps, SD 625I(PAL)@25fps, 525I(NTSC)@30fps |
|
Audio |
Up to 8 channels, 24-bit, 48kHz |
|
Bit Depth |
10/12bit |
|
Color Space |
4:2:2 YCbCr 4:2:0 YCbCr 4:4:4 YCbCr 4:4:4 RGB |
|
Signal amplitude |
800mV±10% |
|
Repeater Function |
Yes |
|
Plug and Play |
Yes |
|
Power Supply |
5V to 12V DC |
|
Power |
<5.5W |
|
Working Tem |
0℃~50℃ no condensation |
|
Storage Tem |
-20℃~50℃ |
|
Work Humidity |
20%~70%RH |
|
Storage Humidity |
0%~90%RH no condensation |
